PN:P100001650
EAN:7640121220760
Product Details
model
compound
Disc 26
Disc C
Fits
SRAM
Brake Calipers
- RED AXS gen 3 E1,AXS gen 2 D1
- Force AXS
- Rival AXS
- Apex AXS
- Level Stealth 2-Piston
- Level Ultimate,TLM B1 (2020+),TL,T,Level Base
- DB 5,3,1
- XX
- XO
Avid
Brake Calipers
- Elixir 9,7,5,3,1,CR,R
Characteristics
High performance Kevlar, ceramic, brass and resin composite material. Provides excellent brake power with minimal effort at the brake lever. Performance is consistent in both wet and dry conditions and pad life is excellent. High quality springs included with every set (where applicable).
performance
0 (worst) - 10 (best)
Initial Bite: 9
Modulation: 8
Longevity: 7
Heat Tolerance: 7
Noise Dry: 9
Noise Wet: 9
Find Your Pads
A life-size drawing of Disc 26 C is available for download.
You can match the shape and dimensions of your pads to help determine if Disc 26 C is the correct fit for your brakes.
PDF file, about 400 KB.
Print at 100% size. Do not use "Fit to page" - a scaled print is not life size.
instructions
info
SwissStop recommends having Disc Brake Pads changed by a professional mechanic at your local authorized SwissStop retailer.
When changing disc pads please clean rotor of any particles and check function of the whole brake system.
Attention: pads must be bedded in to achieve optimal performance
Step 1. On a gradual downhill slope, drag each brake for 20-30 seconds, alternating between front and rear. Repeat 2-3 times.
Step 2. On a steeper slope, engage and drag the brakes for 10-15 seconds then increase lever pressure until the bike slows almost to a complete stop. Repeat 2-3 times.
Pro Tip: The front pads will have been heated more than the rear. To achieve optimal performance, exchange the front and rear pads then repeat Step 2.
CAUTION before replacing or exchanging brake pads it is essential to let all parts cool.
